متریال پمپ استخر لئو XKP00
| قطعه | مواد | . | قطعه | مواد | |
| 1 | Filling Plug | PP | 14 | Terminal Box | ABS |
| 2 | Pump Body | PP | 15 | Terminal Board | PC |
| 3 | Water Proof Cover | PPO | 16 | Terminal Box Cover | ABS |
| 4 | Diffuser | PPO | 17 | Capacitor | |
| 5 | Ball Bearing | 18 | Front Plate | ZL 102 | |
| 6 | Rotor | 19 | Support | PP | |
| 7 | Base | PA | 20 | O-ring | NBR |
| 8 | Stator | 21 | Mechanical Seal | Carbon/Ceramic | |
| 9 | Fan Cover | 08F | 22 | Impeller | PPO |
| 10 | Fan | PP | 23 | Sieve | PP |
| 11 | Rear Cover | ZL 102 | 24 | O-ring | NBR |
| 12 | Motor Housing | ZL 102 | 25 | Nut | ABS |
| 13 | Cable | 26 | Connector | PC |
اطلاعات فنی پمپ استخر LEO XKP00
| MODEL | POWER | Q(m³/h) | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | |
| W | Q(l/min) | 17 | 33 | 50 | 66 | 83 | 100 | 116 | 132 | 150 | 165 | ||
| XKP200-2 | 200 | H (m) | 5.5 | 4.8 | 4 | 3 | 1.8 | 0.6 | ˗ | ˗ | ˗ | ˗ | |
| XKP250-2 | 250 | 6.9 | 6.3 | 5.5 | 4.6 | 3.6 | 2.4 | 1 | ˗ | ˗ | ˗ | ||
| XKP300-2 | 300 | 7.7 | 7.2 | 6.4 | 5.5 | 4.5 | 3 | 1 | ˗ | ˗ | ˗ | ||
| XKP350-2 | 350 | 8.4 | 7.7 | 7 | 6.2 | 5 | 3.8 | 2.3 | 0.8 | ˗ | ˗ | ||
| XKP450-2 | 450 | 9.6 | 9.1 | 8.5 | 8 | 7.3 | 6.4 | 5.2 | 4 | 2.4 | ˗ |
